Small-eye module

For lightweight plush charms that need expressive eyes. Small screens, voice and touch responses let the character talk and respond with its eyes.

Small, expressive eyes

Two 0.85-inch square screens, with a software display area configurable to 0.71 inches. Eye expressions and animations can be designed for the character.

Touch & vibration response

Button voice, touch and vibration are confirmed. Touch-sensor positions can follow the exterior design, with activation checked after plush covering.

For characters on the go

Primarily for screen-equipped plush and expressive charms. Eye positions, covers and internal wiring need to be assessed together.

Module dimensions

56 × 43.8 × 25 mm

Battery & charging

1000 mAh / USB Type-C

Eye screens

Two 0.85-inch square screens; 0.71-inch display area configurable

Screen resolution

160 × 160 px (each screen)

Confirmed interaction

Button voice, eye expressions, touch and vibration

Reference exterior space

At least 11 × 9 × 13 cm (W × D × H)

Eye centre spacing

At least 5.5 cm

Customization

MP4 expression assets can be supplied at the screen’s pixel dimensions. Changing the eye-cover shape requires new tooling. Board reuse, wire length and fixing methods depend on the structure.

Connectivity & character services

Use the mobile app for Wi-Fi setup, then access Tuya voice and character services. The platform response lists 67 languages; target languages, regional versions and content scope are confirmed per project.

Your app & cloud integration

Evaluate app SDK or cloud-to-cloud API integration, covering product settings, device DPs, AI agents and credentials. Access, development scope and fees are confirmed per project.

Firmware & ongoing maintenance

OTA updates run through the mobile app and need stable Wi-Fi and adequate battery. Interaction pauses during updates and the device restarts afterwards. Update and maintenance scope follows the delivered version.
